DUCTILE IRON NOZZLE TYPE FLANGED END,PN16

Model: MV30-412
Category: Check Valves, General Valves
Lineup: N/A

Design: BS EN 12334
Rating: PN16

Connection:

  • Flanged to BS EN1092-2, PN16 (ex BS4504)

Working Medium:

  • Water
  • Oil
  • Steam

Features:

  • Compact structure, saving installation space
  • Can be installed in horizontal or vertical pipes
  • When installed vertically, media flows upward

On Request:

  • ANSI standards (subject to minimum order quantities)

Hydrostatic Test Pressure:

  • Shell: 24 bar
  • Seat: 17.6 bar

Working Temperature Range:

  • 16 bar: -10°C to 110°C (water)

Product Specifications

Pressure Rating
PN16

Connection Type
Flanged to BS EN1092-2,PN16 (ex BS4504)

Product Material
Ductile Iron
