Ductile Iron Hydraulically Operated Pilot Controlled, PN16

Working Pressure: PN16
Connection: Flanged to BS EN1092-2, PN16 (ex BS4504)
Working Medium: Water
Face to Face: EN558-1
Test Standard: ISO 5208/EN12266-1
Set Pressure (SP): ≤ 13.3 bar
Blowdown: ≤ 1 bar (SP < 3 bar)
    ≤ 0.8 * SP (SP ≥ 3 bar)
Features:

• Full port design, low pressure loss when fully opened
• Highly sensitive and reinforced diaphragm
• Stable performance, long service life
• Simple operation, convenient adjusting
• Precise pressure reducing

On Request:

• ANSI standards (subject to minimum order quantities)

Hydrostatic Test Pressure:

• Shell: 25 bar
• Seat: 17.6 bar

Working Temperature:

• 16 Bar: 0° C to 80° C (water)
