Ductile Iron Double flanged, gear operated PN16.,

Model: MV20-241
Category: Butterfly Valves, General Valves
Lineup: N/A

Design: BS EN 593: 2017 | Rating: PN16 | Connection: Flanged to BS EN1092-2, PN16 (ex. BS 4504), Top Flange conforming to ISO 5211

Face-to-Face Dimension: BS EN 558: 2017

Working Medium: Water, Oil, Steam

Valve Inspection and Testing: BS EN 12266-1: 2012

Features:

  • Double flanged design
  • Lever/Gear operated
  • Epoxy coated
  • Replaceable liner
  • EPDM lined

On Request:

  • ANSI standards
  • Chainwheel operator
  • Alternative disc material
  • Electric / Pneumatic actuators
  • Other flange standards
  • Higher sizes (subject to minimum order quantities)

Hydrostatic Test Pressure:

  • Shell: 24 bar
  • Seat: 17.6 bar

Working Temperature:

  • 16 bar: -10°C to 110°C (water)

Product Specifications

Pressure Rating
PN16

Connection Type
Face to Face
BS EN1092-2, PN16
(ex. BS 4504)
Top Flange confirm to
ISO 5211

Product Material
Ductile Iron
